V7 DOCKUCPT2D laptop dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Black

• Easily connect your computer to all of your peripherals with one cable while charging your computer.
• Dual HDMI ports, supporting up to 8K resolution for a single display or dual 4K displays
• USB-C Power Delivery (100W) to your computer and 18W to charge your devices.
• 1m integrated USB-C Cable for convenience and versatility
• Gigabit Ethernet, SD/MicroSD Card reader, and a 3.5mm audio port
• Enjoy a 2-year warranty for worry-free use

The USB-C Alt Mode Dual Display Docking Station is a versatile solution for expanding your laptop's capabilities. With its dual HDMI ports, you can connect two external monitors and enjoy a multi-screen setup for enhanced productivity. Additionally, the docking station offers three USB-A ports for connecting various peripherals, SD/Micro SD card slots for easy file transfer, Gigabit Ethernet for a reliable internet connection, and a 3.5mm audio jack for your headphones or speakers. The USB-C Power Delivery feature allows you to charge your laptop directly from the docking station, using the included 130w power supply for optimal performance.

Ports & interfaces
Connectivity technology	Wired
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
HDMI ports quantity	2
DisplayPorts quantity	2
Microphone in	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
USB connector type	USB Type-A, USB Type-C
DC-in jack	Yes

Network
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10,100,1000 Mbit/s

Performance
Product colour	Black
Card reader integrated	No
Optical drive included	No
Data transfer rate	5 Gbit/s
Maximum digital resolution	5120 x 2880 pixels
Number of displays supported	2
On/off switch	Yes
Charging function	Yes
Country of origin	China
Brand compatibility	Any brand
Certification	CE, FCC

Audio
Built-in speaker(s)	No

Power
Power source type	AC
Output current	3.42 A
Output voltage	19 V
Power consumption (max)	65 W

Software
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Mac compatibility	Yes
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight & dimensions
Width	225 mm
Depth	25 mm
Height	85 mm
Weight	362 g

Packaging data
Quantity per pack	1 pc(s)
Package width	270 mm
Package depth	68 mm
Package height	180 mm
Package weight	1.57 kg

Packaging content
Quick start guide	Yes
AC adapter included	Yes
Cables included	AC, USB, USB Type-C

Technical details
Compliance certificates	RoHS

Logistics data
Harmonized System (HS) code	84733020
