Teltonika PR1KCO28 network antenna MIMO directional antenna SMA/RP-SMA 28 dBi

• Frequency range 1575.42-1610 MHz
• Polarisation RHCP
• Impedance 50 Ω
• LNA reinforcement 28±2 dB
• LNA Noise Figure < 1.5 dB
• Supply voltage 3-5 V DC
• Power consumption < 15 mA
• LNA V.S.W.R. < 2.0
• Connector Male SMA

Teltonika Combo LTE/ GPS/ Wi-Fi antenna
The MIMO Combo antenna consists of 5 integrated antennas: 2 LTE antennas, 2 Wi-Fi antennas and a GPS antenna. It is designed to be mounted on vehicle roofs.

Performance
Antenna gain level (max)	28 dBi
Frequency band	1.57542-1.61; 0.698-0.96/1.71-2.69; 2.4-2.4835/4.9-5.825 GHz
Antenna gain (5 GHz)	2 dBi
Antenna gain (2.4 GHz)	2 dBi
Impedance	50 Ω

Features
Antenna type	MIMO directional antenna
Connector gender	Female/Female
Antenna connector type	SMA/RP-SMA
Polarization	Linear polarization
Voltage Standing Wave Ratio (VSWR)	2/2.5/3
Product colour	Black
Housing material	Acrylonitrile butadiene styrene (ABS)
International Protection (IP) code	IP67
Cable type	5x RG174
Cable length	3 m

Power
Power consumption	15 mA
Input voltage	3-5 V

Certificates
Compliance certificates	RoHS

Weight & dimensions
Height	55 mm
Diameter	11 cm
Weight	550 g

Logistics data
Harmonized System (HS) code	85177100
