- 6 Low Voltage (max 30V) single pole changeover relays
- Individually controllable from any RS232 serial port
- On, Off or Toggle commands
- RS232 Feedback
- Compact design
- Rackmount with RS01 shelf
The SY-RB6 provides RS232 control over the 6 low voltage relays. With connections for RS232 and Normally Open, Normally Closed and Common, the RB6 is the ideal choice to interface with other systems requiring a switch or contact closure.
The RB6 is not suitable for use with power connected to the relays above 30V.
| Design |
|---|
| Product colour |
Black |
| Mounting type |
Rack mounting |
| LED indicators |
Yes |
| Ports & interfaces |
|---|
| Serial interface type |
RS-232 |
| Power |
|---|
| Input voltage |
12 V |
| Input current |
1 A |
| Certificates |
|---|
| Certification |
CE |
