SY Electronics HDBT-231-100 AV transmitter Black

• AV transmitter Black
• Maximum transfer distance: 100 m
• EDID management
• HDCP
• Wired

The HDBT-231-70/100 is a dual HDMI to 3x HDBaseT Transmitter with a local HDMI loop out - Single Zone DA.

The HDBT-231-70 and HDBT-231-100 provide a selection from one of two HDMI input sources and distributes that selection to three HDBaseT outputs and a local HDMI output.

The HDBaseT outputs can respectively broadcast up to 70m/100m @ 1080p or 40m/70m @ 4K 30Hz using cat6a cable (using HDBT-70SE-R or HDBT-100-SLIM-R receivers).

Features
Type	AV transmitter
Maximum transfer distance	100 m
EDID management	Yes
Extended display identification data (EDID)	Yes
RS-232 pass-through	Yes
Bidirectional	Yes
IR pass-through	Yes
Bandwidth	10.2 Gbit/s
HDCP version	2.2
HDCP	Yes
Rack mounting	Yes
Supported video modes	1080p
Product colour	Black

Ports & interfaces
Connectivity technology	Wired
RJ-45 output ports	3
HDBaseT port	Yes
HDMI version	2.0
Number of HDMI outputs	1
HDMI in	2
Remote (IR) output	1
Remote (IR) input	1
3.5 mm (1/8-inch) out	Yes
3.5 mm (1/8-inch) in	Yes
Audio output	1

Power
Operating voltage	48 V

Packaging data
Quantity per pack	1 pc(s)
