Opengear CM8116-10G-USB console server RS-232/RJ-45

• 10Gb SFP+ uplinks connect directly to high-speed networks on select models
• REST API, Docker, and Python support for data center automation
• Dual power supplies with independent monitoring
• Port auto-discovery simplifies serial settings and port labels
• Selectable software serial ports eliminate serial adapters on select models
• Ideal replacement for legacy terminal servers
• Ships with two C14 power cables standard

The CM8100 Series is Opengear’s high-density console manager, built to keep critical infrastructure reachable under any condition. It supports up to 96 serial ports across 1GbE and 10GbE models, with select models adding 5G cellular (-C) for resilient out-of-band access. TPM 2.0 delivers enterprise-grade hardware security, and REST API, Docker, and Python support let teams run automation at the edge. Manage every device and site at scale through Opengear’s Lighthouse® Software.

Secure remote access for data centers, enterprise networks, and edge sites
16, 32, 48, and 96 port serial console server with Smart Out-of-Band
Built-in 5G cellular modem on C models for added bandwidth and reliability
Hardware-based TPM 2.0 provides secure boot
Manage at scale through Opengear Lighthouse

Technical details
Mobile network generation	5G
Cellular	Yes
Compliance certificates	RoHS
Supported programming languages	Perl, Python
MIB support	Yes
Product colour	Black, Red
Temperature sensor	Yes
Web-based management	Yes
Zero Touch Provisioning (ZTP)	Yes
Rack mounting	Yes

Security
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Authentication method	TACACS+, RADIUS, OpenLDAP
Security algorithms	IPSec, SNMP, SSH

Ports & interfaces
Console port	RS-232/RJ-45
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	8
Serial ports quantity	16
AC outlet types	C14 coupler

Features
Cooling type	Passive

Network
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T

Processor
Processor family	Marvell
Processor architecture	ARM Cortex-A9
Processor cores	2
Processor frequency	1600 MHz

Memory
eMMC capacity	32 GB
Internal memory	2000 MB
RAM type	DDR4
Flash memory	32000 MB

Operational conditions
Operating relative humidity (H-H)	5 - 90%
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 50 °C

Power
AC input voltage	100 - 240 V
Number of power supply units	2
