Vendeur: Gigabyte

GIGABYTE P650G PCIE 5.1 Power Supply - PCIe 5.1, 80 PLUS Silver, 120mm Fan, ATX 3.1 compatible, EU Plug

65,34 €32,74 €Promotion
Quantité

Détails du produit

  • ATX 3.1 and PCIe Gen 5.1 ready
  • 80 PLUS Gold certified
  • Main Japanese capacitors
  • 120mm Silent Hydraulic Bearing (HYB) Fan
  • Powerful single +12V rail
  • OVP/OPP/SCP/UVP/OCP/OTP protection
  • Compact design

Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.

Power
Power protection features Over power, Overcharge, Short circuit, Under voltage
Power Good signal delay range 100 - 150 ms
Max output current (+5Vsb) 18 A
Max output current (-12V) 0.3 A
Max output current (+5V) 18 A
Max output current (+12V) 54.2 A
Max output current (+3.3V) 18 A
Combined power (+5Vsb) 15 W
Combined power (-12V) 3.6 W
Combined power (+5V) 650 W
Combined power (+12V) 650 W
Combined power (+3.3V) 90 W
Power Factor Correction (PFC) type Active
Maximum input current (@220V) 6 A
Maximum input current (@110V) 10 A
Input current 10 - 6 A
AC input frequency 50/60 Hz
AC input voltage 100 - 240 V
Total power 650 W
Ports & interfaces
Cabling type Non-Modular
Floppy disk drive connector Yes
ATX power connector (20+4 pin) Yes
CPU power cable length 60 cm
CPU power connector (4+4 pin) Yes
CPU P4 connector (4-pin) 1
PCI Express power cable length 50 cm
PCI Express power connectors (6+2 pin) 2
Peripheral (Molex) power cable length 150 mm
Peripheral (Molex) power connectors (4-pin) 3
SATA power cable length 120,500 mm
Number of SATA power connectors 6
Motherboard power cable length 60 cm
Motherboard power connector 20+4 pin ATX
Performance
Mean time between failures (MTBF) 100000 h
Bearing technology HYB
ATX version 3.1
80 PLUS certification 80 PLUS Gold
Power supply unit (PSU) form factor ATX
Purpose PC
Design
On/off switch Yes
Fan location Top
Number of fans 1 fan(s)
Fan diameter 12 cm
Cooling type Active
Product colour Black
Weight & dimensions
Weight 1.76 kg
Height 86 mm
Depth 150 mm
Width 140 mm
Packaging data
Package type Box
Package weight 1.92 kg
Package height 180 mm
Package depth 110 mm
Package width 260 mm
Logistics data
Warranty period 5 year(s)
