Cablenet Loaded Fibre Patch Panel OM3/4 12 Fibre - 6 x LC Duplex

• OM3/4 (50/125)
• Loaded with 6 x LC Duplex Couplers
• Cable Glands, Bunny Clips, and Splice Cassettes included
• High-Quality Sliding Mechanism

OM3/4 Multimode Loaded Fibre Patch Panel to accept 12 fibres connecting to 6 LC duplex adaptors.

Capacity can be increased by removing the blanking plugs and replacing with the appropriate adaptor.

The Maxxam Loaded Fibre Patch Panels have been developed to help save time and money when on site. The panels are supplied with the adaptors installed in the front plate and the front plate subsequently mounted on to the panel chassis. The 19-inch mounting brackets are also fitted to the panel chassis so that the panel is ready to be mounted into the rack or cabinet. The panels are supplied with cable glands, bunny clips and splice cassettes and any unused ports are fitted with blanking plugs.

The fibre panels are available with Multimode (OM3 or OM4) or Singlemode adaptors and are configured for 4 to 96 fibres with LC adaptors or 8 to 48 fibres with SC adaptors.

Network
Duplex	Yes
Ports quantity	12
Connector(s)	LC
Cable types supported	Fiber
Fiber ports quantity	12
Fiber optic connector	LC
Multi-mode fiber (MMF) supported	Yes
Single-mode fiber (SMF) supported	No

Design
Product colour	Black
Material	Metal
Mounting	Rack mounting
Rack capacity	1U
Cable management	Yes
Label holder	No

Weight & dimensions
Width	424 mm
Height	225 mm
Depth	44 mm
