Allied Telesis AT-DMC100/LC-90 network media converter 100 Mbit/s 1310 nm Multi-mode Grey

• Wired
• 100 Mbit/s 2000 m 1310 nm
• 100BASE-FX
• Ethernet LAN (RJ-45) ports: 1
• Multi-mode Fiber ports quantity: 1 LC 50/125,62.5/125 µm
• DIN rail mounting
• Grey

Overview

At just 1.25 inches wide × 3.6 inches deep × 0.85 inches high, Allied Telesis DMC Series media converters can easily fit into the palm of a hand. In addition to being compact—with a small carbon footprint—the DMC Series can also be powered with the included Micro USB to USB cable, and plugged directly into a laptop or PC or may also be powered via the optional AC/DC adapter. This saves installation time and cabling as there are no further power requirements

Network
Link Loss Return (LLR) supported	Yes
Link Loss Carry Forward (LLCF) supported	Yes
Duplex system	Full, Half
Auto-negotiation	Yes
Auto MDI/MDI-X	Yes
Data transfer rate	100 Mbit/s
Fiber ethernet cabling technology	100BASE-FX
Networking standards	IEEE 802.1Q
Converter output interface	100Base-FX
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s

Performance
Rx power (max)	-14 dBmW
Rx power (min)	-32 dBmW
Tx power (max)	-14 dBmW
Tx power (min)	-22.5 dBmW
Fiber cable diameters supported (core/cladding)	50/125,62.5/125 µm
Fiber mode structure	Multi-mode
Wavelength	1310 nm
Maximum transfer distance	2000 m

Features
LED indicators	Yes
Product colour	Grey
DIN rail mounting	Yes
Internal	No

Ports & interfaces
Fiber optic connector	LC
Fiber ports quantity	1
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired

Weight & dimensions
Height	21.6 mm
Depth	91.4 mm
Width	31.8 mm

Operational conditions
Operating altitude	0 - 3048 m
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	5 - 95%
Storage temperature (T-T)	-15 - 65 °C
Operating temperature (T-T)	0 - 40 °C

Certificates
Compliance certificates	RoHS
